usb RAID

USB " RAID"

USB RAID

Key feature

MU-7010 ( usb Raid ) with our special designed controller it support “ dual channel transition “ and “ Pipeline burst engine “ inside , it perform an excellent transfer rate from Micro SD to USB .

MU-7010 ( usb Raid ) has the ability to support 2 piece micro SD to integrated 2 cards' capacity into one , maximum the usage of micro SD , plus its higher speed transition rate and higher capacity , user has more functions to use it ,
  • Support Micro SD / SD 1.1 , SD2.0 (SDHC)
  • High speed tr a nsfer rate
  • Hot Plug & Play
  • Multi Color supported
  • Integrate 2 MicroSD / SD card's memory capacity into 1 SSD USB drive
  • Format as a hard drive
  • USB 2.0 480Mbps high-speed compatible
  • USB 1.1 Mass Storage Class compliant
  • USB Mass Storage Class Bulk-Only Transport 1.0 supported
  • USB Mass Storage Class SCSI transparent command set supported
  • Support ZIP / HDD / CD-ROM format through mass production tool
  • Support CD-RW function (Optional)
  • Support 1 / 2 channel mode for speed improvement
  •  Support up to 256G bytes of disk capacity
  •  Embedded FIFO for upstream and downstream data transfer
  •  PC boot up capability (host BIOS with USB boot up support is necessary)
  •  No driver needed under Microsoft Windows Vista / ME / 2000 / XP / Windows 7, Mac OS 8.6 / 9.x / 10.x, No driver needed for Linux kernel 2.4 or above

Testing report

Roughly Testing report for 7010
TF
Testing tool
Single
double
W
R
W
R
Toshiba 1G
ATTO Bench
7304
16353
14565
23776
HD bench
5648
15778
9098
22985
Sandisk 4G C2
ATTO Bench
7173
16704
13901
23839
Toshiba 4G C4
ATTO Bench
10137
16229
16338
23797

..........For More information
